EL7155CN Renesas IC GATE DRV HI-SIDE/LO-SIDE 8DIP
EL7155CN Images
EL7155CN Images
EL7155CN
  • Manufacturer: Renesas Electronics
  • Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 8-DIP (0.300, 7.62mm)
  • Description: IC GATE DRV HI-SIDE/LO-SIDE 8DIP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
EL7155CN Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
EL7155CN Specifications:
  • MfrPart.: EL7155CN
  • Mfr: Renesas Electronics America Inc
  • Description: IC GATE DRV HI-SIDE/LO-SIDE 8DIP
  • Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • DrivenConfiguration: High-Side or Low-Side
  • ChannelType: Synchronous
  • NumberofDrivers: 2
  • GateType: IGBT
  • Voltage-Supply: 4.5V ~ 16.5V
  • LogicVoltage-VILVIH: 0.8V, 2.4V
  • Current-PeakOutput(SourceSink): 3.5A, 3.5A
  • InputType: Non-Inverting
  • HighSideVoltage-Max(Bootstrap): -
  • Rise/FallTime(Typ): 14.5ns, 15ns
  • OperatingTemperature: -40°C ~ 125°C (TJ)
  • MountingType: Through Hole
  • Package/Case: 8-DIP (0.300, 7.62mm)
  • EL7155CN Renesas, IC GATE DRV HI-SIDE/LO-SIDE 8DIP, Integrated Circuits (ICs)~PMIC - Gate Drivers
