HI1-0509-4 Images
- Manufacturer: Renesas Electronics
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-CDIP (0.300, 7.62mm)
- Description: 4-CHANNEL CMOS ANALOG MUX
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HI1-0509-4 Specifications:
- MfrPart.: HI1-0509-4
- Mfr: Intersil (Now part of Renesas Electronics America Inc)
- Description: 4-CHANNEL CMOS ANALOG MUX
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 400Ohm
- Channel-to-ChannelMatching(ΔRon): 20Ohm
- Voltage-SupplySingle(V+): -
- Voltage-SupplyDual(V±): ±15V
- SwitchTime(TonToff)(Max): 500ns, 500ns
- -3dbBandwidth: -
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 10pF, 30pF
- Current-Leakage(IS(off))(Max): 30pA (Typ)
- Crosstalk: -
- OperatingTemperature: -25°C ~ 85°C (TA)
- MountingType: Through Hole
- Package/Case: 16-CDIP (0.300, 7.62mm)
- HI1-0509-4 Renesas, 4-CHANNEL CMOS ANALOG MUX, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
HI1-0509-4, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
