UPA503T-T2-A Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: TO-236-3, SC-59, SOT-23-3
- Description: SMALL SIGNAL P-CHANNEL MOSFET
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
UPA503T-T2-A Specifications:
- MfrPart.: UPA503T-T2-A
- Mfr: Renesas Electronics America Inc
- Description: SMALL SIGNAL P-CHANNEL MOSFET
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: 2 P-Channel (Dual)
- FETFeature: Standard
- DraintoSourceVoltage(Vdss): 50V
- Current-ContinuousDrain(Id)@25°C: 100mA
- RdsOn(Max)@IdVgs: 60Ohm @ 10mA, 10V
- Vgs(th)(Max)@Id: 2.5V @ 1µA
- GateCharge(Qg)(Max)@Vgs: -
- InputCapacitance(Ciss)(Max)@Vds: 17pF @ 5V
- Power-Max: 300mW
- OperatingTemperature: -
- MountingType: Surface Mount
- Package/Case: TO-236-3, SC-59, SOT-23-3
- UPA503T-T2-A Renesas, SMALL SIGNAL P-CHANNEL MOSFET, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
UPA503T-T2-A, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
