UPA2766T1A-E2-AY Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-HVSON (5x5.4)
- Description: MOSFET N-CH 30V 130A 8HVSON
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
UPA2766T1A-E2-AY Specifications:
- MfrPart.: UPA2766T1A-E2-AY
- Mfr: Renesas Electronics America Inc
- Description: MOSFET N-CH 30V 130A 8HVSON
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Last Time Buy
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 130A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 1.82mOhm @ 39A, 4.5V
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: 257 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 10850 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 1.5W (Ta), 83W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-HVSON (5x5.4)
- UPA2766T1A-E2-AY Renesas, MOSFET N-CH 30V 130A 8HVSON, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
