RJK03P7DPA-00#J5A Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 8-WFDFN Exposed Pad
- Description: POWER, N-CHANNEL MOSFET
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
RJK03P7DPA-00#J5A Specifications:
- MfrPart.: RJK03P7DPA-00#J5A
- Mfr: Renesas Electronics America Inc
- Description: POWER, N-CHANNEL MOSFET
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: 2 N-Channel (Half Bridge)
- FETFeature: Logic Level Gate, 4.5V Drive
- DraintoSourceVoltage(Vdss): 30V
- Current-ContinuousDrain(Id)@25°C: 15A, 30A
- RdsOn(Max)@IdVgs: 9.4mOhm @ 7.5A, 10V
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: 7.1nC @ 4.5V
- InputCapacitance(Ciss)(Max)@Vds: 1190pF @ 10V
- Power-Max: 10W, 20W
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-WFDFN Exposed Pad
- RJK03P7DPA-00#J5A Renesas, POWER, N-CHANNEL MOSFET, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
RJK03P7DPA-00#J5A, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
