RJK03M1DPA-00#J5A Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: WPAK(3F) (5x6)
- Description: MOSFET N-CH 30V 50A 8WPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
RJK03M1DPA-00#J5A Specifications:
- MfrPart.: RJK03M1DPA-00#J5A
- Mfr: Renesas Electronics America Inc
- Description: MOSFET N-CH 30V 50A 8WPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 50A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 2.3mOhm @ 25A, 10V
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: 25 nC @ 4.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 4720 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 45W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: WPAK(3F) (5x6)
- RJK03M1DPA-00#J5A Renesas, MOSFET N-CH 30V 50A 8WPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
