RJH60T04DPQ-A0#T0 Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT TH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
RJH60T04DPQ-A0#T0 Specifications:
- MfrPart.: RJH60T04DPQ-A0#T0
- Mfr: Renesas Electronics America Inc
- Description: IGBT TH
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tray
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 60 A
- Current-CollectorPulsed(Icm): 180 A
- Vce(on)(Max)@VgeIc: 1.95V @ 15V, 30A
- Power-Max: 208.3 W
- SwitchingEnergy: -
- InputType: Standard
- GateCharge: 87 nC
- Td(on/off)@25°C: 54ns/136ns
- TestCondition: 300V, 30A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 100 ns
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- RJH60T04DPQ-A0#T0 Renesas, IGBT TH, Discrete Semiconductor Products~Transistors - IGBTs - Single
RJH60T04DPQ-A0#T0, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
