RJH60D6DPM-00#T1 Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3 Full Pack
- Description: IGBT 600V 80A 50W TO-3PFM
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
RJH60D6DPM-00#T1 Specifications:
- MfrPart.: RJH60D6DPM-00#T1
- Mfr: Renesas Electronics America Inc
- Description: IGBT 600V 80A 50W TO-3PFM
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): -
- Vce(on)(Max)@VgeIc: 2.2V @ 15V, 40A
- Power-Max: 50 W
- SwitchingEnergy: 850µJ (on), 600µJ (off)
- InputType: Standard
- GateCharge: 104 nC
- Td(on/off)@25°C: 50ns/160ns
- TestCondition: 300V, 40A, 5Ohm, 15V
- ReverseRecoveryTime(trr): 100 ns
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3 Full Pack
- RJH60D6DPM-00#T1 Renesas, IGBT 600V 80A 50W TO-3PFM, Discrete Semiconductor Products~Transistors - IGBTs - Single
RJH60D6DPM-00#T1, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
