RJH60D1DPP-M0#T2 Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3 Full Pack
- Description: IGBT 600V 20A 20.8W TO220FL
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
RJH60D1DPP-M0#T2 Specifications:
- MfrPart.: RJH60D1DPP-M0#T2
- Mfr: Renesas Electronics America Inc
- Description: IGBT 600V 20A 20.8W TO220FL
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 20 A
- Current-CollectorPulsed(Icm): -
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 10A
- Power-Max: 30 W
- SwitchingEnergy: 100µJ (on), 130µJ (off)
- InputType: Standard
- GateCharge: 13 nC
- Td(on/off)@25°C: 30ns/42ns
- TestCondition: 300V, 10A, 5Ohm, 15V
- ReverseRecoveryTime(trr): 70 ns
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3 Full Pack
- RJH60D1DPP-M0#T2 Renesas, IGBT 600V 20A 20.8W TO220FL, Discrete Semiconductor Products~Transistors - IGBTs - Single
RJH60D1DPP-M0#T2, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
