RJH60D0DPM-00#T1 Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3 Full Pack
- Description: IGBT 600V 45A 40W TO3PFM
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
RJH60D0DPM-00#T1 Specifications:
- MfrPart.: RJH60D0DPM-00#T1
- Mfr: Renesas Electronics America Inc
- Description: IGBT 600V 45A 40W TO3PFM
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 45 A
- Current-CollectorPulsed(Icm): -
- Vce(on)(Max)@VgeIc: 2.2V @ 15V, 22A
- Power-Max: 40 W
- SwitchingEnergy: 230µJ (on), 290µJ (off)
- InputType: Standard
- GateCharge: 46 nC
- Td(on/off)@25°C: 40ns/80ns
- TestCondition: 300V, 22A, 5Ohm, 15V
- ReverseRecoveryTime(trr): 100 ns
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3 Full Pack
- RJH60D0DPM-00#T1 Renesas, IGBT 600V 45A 40W TO3PFM, Discrete Semiconductor Products~Transistors - IGBTs - Single
