RJH1CV5DPK-00#T0 Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3 Full Pack
- Description: IGBT 1200V 50A 245W TO-3P
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
RJH1CV5DPK-00#T0 Specifications:
- MfrPart.: RJH1CV5DPK-00#T0
- Mfr: Renesas Electronics America Inc
- Description: IGBT 1200V 50A 245W TO-3P
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Last Time Buy
- IGBTType: Trench
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 50 A
- Current-CollectorPulsed(Icm): -
- Vce(on)(Max)@VgeIc: 2.6V @ 15V, 25A
- Power-Max: 245 W
- SwitchingEnergy: 1.9mJ (on), 1.5mJ (off)
- InputType: Standard
- GateCharge: 72 nC
- Td(on/off)@25°C: 42ns/105ns
- TestCondition: 600V, 25A, 5Ohm, 15V
- ReverseRecoveryTime(trr): 170 ns
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3 Full Pack
- RJH1CV5DPK-00#T0 Renesas, IGBT 1200V 50A 245W TO-3P, Discrete Semiconductor Products~Transistors - IGBTs - Single
RJH1CV5DPK-00#T0, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
