RJH1CM5DPQ-E0#T2 Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT, 30A, 1200V, N-CHANNEL, TO-
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
RJH1CM5DPQ-E0#T2 Specifications:
- MfrPart.: RJH1CM5DPQ-E0#T2
- Mfr: Renesas Electronics America Inc
- Description: IGBT, 30A, 1200V, N-CHANNEL, TO-
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 1.2 kV
- Current-Collector(Ic)(Max): 30 A
- Current-CollectorPulsed(Icm): -
- Vce(on)(Max)@VgeIc: 2.7V @ 15V, 15A
- Power-Max: 245 W
- SwitchingEnergy: 1.6mJ (on), 700µJ (off)
- InputType: Standard
- GateCharge: 74 nC
- Td(on/off)@25°C: 40ns/100ns
- TestCondition: 600V, 15A, 5Ohm, 15V
- ReverseRecoveryTime(trr): 200 ns
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- RJH1CM5DPQ-E0#T2 Renesas, IGBT, 30A, 1200V, N-CHANNEL, TO-, Discrete Semiconductor Products~Transistors - IGBTs - Single
RJH1CM5DPQ-E0#T2, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
