PS9822-2-F3-AX Images
- Manufacturer: Renesas Electronics
- Category: Isolators~Optoisolators - Logic Output Package/Case: 8-SOIC (0.154, 3.90mm Width)
- Description: HI-SPEED OPTOCPLR SO-8
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PS9822-2-F3-AX Specifications:
- MfrPart.: PS9822-2-F3-AX
- Mfr: Renesas Electronics America Inc
- Description: HI-SPEED OPTOCPLR SO-8
- Product Category: Isolators~Optoisolators - Logic Output
- Package: Tape & Reel (TR)
- Series: NEPOC
- PartStatus: Active
- NumberofChannels: 2
- Inputs-Side1/Side2: 2/0
- Voltage-Isolation: 2500Vrms
- CommonModeTransientImmunity(Min): -
- InputType: DC
- OutputType: Open Collector
- Current-Output/Channel: 25 mA
- DataRate: 1Mbps
- PropagationDelaytpLH/tpHL(Max): 700ns, 500ns
- Rise/FallTime(Typ): -
- Voltage-Forward(Vf)(Typ): 1.6V
- Current-DCForward(If)(Max): 15mA
- Voltage-Supply: 7V
- OperatingTemperature: -40°C ~ 100°C
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width)
- PS9822-2-F3-AX Renesas, HI-SPEED OPTOCPLR SO-8, Isolators~Optoisolators - Logic Output
PS9822-2-F3-AX, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
