PS9402-E3-AX Images
- Manufacturer: Renesas Electronics
- Category: Isolators~Isolators - Gate Drivers Package/Case: 16-SOIC (0.295, 7.50mm Width)
- Description: OPTOISO 5KV 1CH GATE DRVR 16SSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PS9402-E3-AX Specifications:
- MfrPart.: PS9402-E3-AX
- Mfr: Renesas Electronics America Inc
- Description: OPTOISO 5KV 1CH GATE DRVR 16SSOP
- Product Category: Isolators~Isolators - Gate Drivers
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- Technology: Optical Coupling
- NumberofChannels: 1
- Voltage-Isolation: 5000Vrms
- CommonModeTransientImmunity(Min): 25kV/µs
- PropagationDelaytpLH/tpHL(Max): 200ns, 200ns
- PulseWidthDistortion(Max): 100ns
- Rise/FallTime(Typ): 50ns, 50ns
- Current-OutputHighLow: 2A, 2A
- Current-PeakOutput: 2.5A
- Voltage-Forward(Vf)(Typ): 1.56V
- Current-DCForward(If)(Max): 25 mA
- Voltage-OutputSupply: 15V ~ 30V
- OperatingTemperature: -40°C ~ 110°C
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.295, 7.50mm Width)
- PS9402-E3-AX Renesas, OPTOISO 5KV 1CH GATE DRVR 16SSOP, Isolators~Isolators - Gate Drivers
PS9402-E3-AX, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
