PS9306L-AX Images
- Manufacturer: Renesas Electronics
- Category: Isolators~Isolators - Gate Drivers Package/Case: 6-SOIC (0.268, 6.80mm Width)
- Description: OPTOISO 5KV GATE DRIVER 6SDIP GW
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PS9306L-AX Specifications:
- MfrPart.: PS9306L-AX
- Mfr: Renesas Electronics America Inc
- Description: OPTOISO 5KV GATE DRIVER 6SDIP GW
- Product Category: Isolators~Isolators - Gate Drivers
- Package: Strip
- Series: -
- PartStatus: Active
- Technology: Optical Coupling
- NumberofChannels: 1
- Voltage-Isolation: 5000Vrms
- CommonModeTransientImmunity(Min): 25kV/µs
- PropagationDelaytpLH/tpHL(Max): 400ns, 400ns
- PulseWidthDistortion(Max): 250ns
- Rise/FallTime(Typ): 50ns, 50ns
- Current-OutputHighLow: 400mA, 400mA
- Current-PeakOutput: 600mA
- Voltage-Forward(Vf)(Typ): 1.56V
- Current-DCForward(If)(Max): 25 mA
- Voltage-OutputSupply: 10V ~ 30V
- OperatingTemperature: -40°C ~ 110°C
- MountingType: Surface Mount
- Package/Case: 6-SOIC (0.268, 6.80mm Width)
- PS9306L-AX Renesas, OPTOISO 5KV GATE DRIVER 6SDIP GW, Isolators~Isolators - Gate Drivers
PS9306L-AX, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
