PS2815-4-L-A Images
- Manufacturer: Renesas Electronics
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 16-SOIC (0.173, 4.40mm Width)
- Description: OPTOISO 2.5KV 4CH TRANS 16SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PS2815-4-L-A Specifications:
- MfrPart.: PS2815-4-L-A
- Mfr: Renesas Electronics America Inc
- Description: OPTOISO 2.5KV 4CH TRANS 16SOIC
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: NEPOC
- PartStatus: Active
- NumberofChannels: 4
- Voltage-Isolation: 2500Vrms
- CurrentTransferRatio(Min): 100% @ 1mA
- CurrentTransferRatio(Max): 400% @ 1mA
- TurnOn/TurnOffTime(Typ): -
- Rise/FallTime(Typ): 4µs, 5µs
- InputType: AC, DC
- OutputType: Transistor
- Voltage-Output(Max): 40V
- Current-Output/Channel: 40mA
- Voltage-Forward(Vf)(Typ): 1.15V
- Current-DCForward(If)(Max): 50 mA
- VceSaturation(Max): 300mV
- OperatingTemperature: -55°C ~ 100°C
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.173, 4.40mm Width)
- PS2815-4-L-A Renesas, OPTOISO 2.5KV 4CH TRANS 16SOIC, Isolators~Optoisolators - Transistor, Photovoltaic Output
PS2815-4-L-A, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
