PS2561L1-1-H-A Images
- Manufacturer: Renesas Electronics
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 4-DIP (0.400, 10.16mm)
- Description: OPTOISOLATOR 5KV TRANS 4DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PS2561L1-1-H-A Specifications:
- MfrPart.: PS2561L1-1-H-A
- Mfr: Renesas Electronics America Inc
- Description: OPTOISOLATOR 5KV TRANS 4DIP
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: NEPOC
- PartStatus: Active
- NumberofChannels: 1
- Voltage-Isolation: 5000Vrms
- CurrentTransferRatio(Min): 80% @ 5mA
- CurrentTransferRatio(Max): 160% @ 5mA
- TurnOn/TurnOffTime(Typ): -
- Rise/FallTime(Typ): 3µs, 5µs
- InputType: DC
- OutputType: Transistor
- Voltage-Output(Max): 80V
- Current-Output/Channel: 50mA
- Voltage-Forward(Vf)(Typ): 1.17V
- Current-DCForward(If)(Max): 80 mA
- VceSaturation(Max): 300mV
- OperatingTemperature: -55°C ~ 100°C
- MountingType: Through Hole
- Package/Case: 4-DIP (0.400, 10.16mm)
- PS2561L1-1-H-A Renesas, OPTOISOLATOR 5KV TRANS 4DIP, Isolators~Optoisolators - Transistor, Photovoltaic Output
PS2561L1-1-H-A, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
