PS2505L-4-E3-A Images
- Manufacturer: Renesas Electronics
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 16-SMD, Gull Wing
- Description: OPTOISOLTR 5KV 4CH TRANS 16-SMD
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PS2505L-4-E3-A Specifications:
- MfrPart.: PS2505L-4-E3-A
- Mfr: Renesas Electronics America Inc
- Description: OPTOISOLTR 5KV 4CH TRANS 16-SMD
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: NEPOC
- PartStatus: Discontinued at
- NumberofChannels: 4
- Voltage-Isolation: 5000Vrms
- CurrentTransferRatio(Min): 80% @ 5mA
- CurrentTransferRatio(Max): 600% @ 5mA
- TurnOn/TurnOffTime(Typ): -
- Rise/FallTime(Typ): 3µs, 5µs
- InputType: AC, DC
- OutputType: Transistor
- Voltage-Output(Max): 80V
- Current-Output/Channel: 50mA
- Voltage-Forward(Vf)(Typ): 1.17V
- Current-DCForward(If)(Max): 80 mA
- VceSaturation(Max): 300mV
- OperatingTemperature: -55°C ~ 100°C
- MountingType: Surface Mount
- Package/Case: 16-SMD, Gull Wing
- PS2505L-4-E3-A Renesas, OPTOISOLTR 5KV 4CH TRANS 16-SMD, Isolators~Optoisolators - Transistor, Photovoltaic Output
PS2505L-4-E3-A, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
