NP90N04VDK-E1-AY Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-252 (MP-3ZP)
- Description: POWER DEVICE AUTOMOTIVE MOS MP-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NP90N04VDK-E1-AY Specifications:
- MfrPart.: NP90N04VDK-E1-AY
- Mfr: Renesas Electronics America Inc
- Description: POWER DEVICE AUTOMOTIVE MOS MP-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 90A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 2.8mOhm @ 45A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 102 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 5850 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 1.2W (Ta), 147W (Tc)
- OperatingTemperature: 175°C
- MountingType: Surface Mount
- SupplierDevicePackage: TO-252 (MP-3ZP)
- NP90N04VDK-E1-AY Renesas, POWER DEVICE AUTOMOTIVE MOS MP-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
