NP82N03PUG-E1-AY Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-263 (D²Pak)
- Description: MOSFET N-CH 30V 82A TO263
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NP82N03PUG-E1-AY Specifications:
- MfrPart.: NP82N03PUG-E1-AY
- Mfr: Renesas Electronics America Inc
- Description: MOSFET N-CH 30V 82A TO263
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 82A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 2.8mOhm @ 41A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 160 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 9080 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 1.8W (Ta), 143W (Tc)
- OperatingTemperature: 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-263 (D²Pak)
- NP82N03PUG-E1-AY Renesas, MOSFET N-CH 30V 82A TO263, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NP82N03PUG-E1-AY, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
