NP80N04MHE-S18-AY Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220
- Description: MOSFET N-CH 40V 80A TO220
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NP80N04MHE-S18-AY Specifications:
- MfrPart.: NP80N04MHE-S18-AY
- Mfr: Renesas Electronics America Inc
- Description: MOSFET N-CH 40V 80A TO220
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 80A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): -
- RdsOn(Max)@IdVgs: 8mOhm @ 40A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 60 nC @ 10 V
- Vgs(Max): -
- InputCapacitance(Ciss)(Max)@Vds: 3.3 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 1.8W (Ta), 120W (Tc)
- OperatingTemperature: 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220
- NP80N04MHE-S18-AY Renesas, MOSFET N-CH 40V 80A TO220, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NP80N04MHE-S18-AY, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
