NP70N10KUF-E1-AY Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-263
- Description: MOSFET N-CH 100V 70A TO263
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NP70N10KUF-E1-AY Specifications:
- MfrPart.: NP70N10KUF-E1-AY
- Mfr: Renesas Electronics America Inc
- Description: MOSFET N-CH 100V 70A TO263
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 70A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 20mOhm @ 35A, 10V
- Vgs(th)(Max)@Id: 3.3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 75 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3750 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 1.8W (Ta), 120W (Tc)
- OperatingTemperature: 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-263
- NP70N10KUF-E1-AY Renesas, MOSFET N-CH 100V 70A TO263, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NP70N10KUF-E1-AY, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
