NP45N06VDK-E1-AY Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-252 (MP-3ZP)
- Description: MOSFET N-CH 60V 45A TO252
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NP45N06VDK-E1-AY Specifications:
- MfrPart.: NP45N06VDK-E1-AY
- Mfr: Renesas Electronics America Inc
- Description: MOSFET N-CH 60V 45A TO252
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Not For New Designs
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 45A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 11.6mOhm @ 23A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 38 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2300 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 1.2W (Ta), 75W (Tc)
- OperatingTemperature: 175°C
- MountingType: Surface Mount
- SupplierDevicePackage: TO-252 (MP-3ZP)
- NP45N06VDK-E1-AY Renesas, MOSFET N-CH 60V 45A TO252, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NP45N06VDK-E1-AY, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
