NP20P06YLG-E1-AY Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-HSON
- Description: MOSFET P-CH 60V 20A 8HSON
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NP20P06YLG-E1-AY Specifications:
- MfrPart.: NP20P06YLG-E1-AY
- Mfr: Renesas Electronics America Inc
- Description: MOSFET P-CH 60V 20A 8HSON
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Not For New Designs
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 20A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 47mOhm @ 10A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 51 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2407 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 1W (Ta), 57W (Tc)
- OperatingTemperature: 175°C
- MountingType: Surface Mount
- SupplierDevicePackage: 8-HSON
- NP20P06YLG-E1-AY Renesas, MOSFET P-CH 60V 20A 8HSON, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
