NP180N04TUG-E1-AY Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-263-7
- Description: 180A, 40V, N-CHANNEL MOSFET
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NP180N04TUG-E1-AY Specifications:
- MfrPart.: NP180N04TUG-E1-AY
- Mfr: Renesas Electronics America Inc
- Description: 180A, 40V, N-CHANNEL MOSFET
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 180A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 1.5mOhm @ 90A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 390 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 25.7 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 1.8W (Ta), 288W (Tc)
- OperatingTemperature: 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-263-7
- NP180N04TUG-E1-AY Renesas, 180A, 40V, N-CHANNEL MOSFET, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
