NP100N04PUK-E1-AY Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-263
- Description: N-CHANNEL MOSFET
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NP100N04PUK-E1-AY Specifications:
- MfrPart.: NP100N04PUK-E1-AY
- Mfr: Renesas Electronics America Inc
- Description: N-CHANNEL MOSFET
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 100A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 2.3mOhm @ 50A, 10V
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: 120 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 7.05 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 1.8W (Ta), 176W (Tc)
- OperatingTemperature: 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-263
- NP100N04PUK-E1-AY Renesas, N-CHANNEL MOSFET, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
