KGF12N05-400-SP Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 6-WLCSP (1.47x1.47)
- Description: MOSFET N-CH 5.5V 12A 6WLCSP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
KGF12N05-400-SP Specifications:
- MfrPart.: KGF12N05-400-SP
- Mfr: Renesas Electronics America Inc
- Description: MOSFET N-CH 5.5V 12A 6WLCSP
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 5.5 V
- Current-ContinuousDrain(Id)@25°C: 12A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 3.5V, 4.5V
- RdsOn(Max)@IdVgs: 2.4mOhm @ 12A, 4.5V
- Vgs(th)(Max)@Id: 800mV @ 250µA
- GateCharge(Qg)(Max)@Vgs: 6 nC @ 3.5 V
- Vgs(Max): ±5.5V
- InputCapacitance(Ciss)(Max)@Vds: 940 pF @ 5.5 V
- FETFeature: -
- PowerDissipation(Max): 2.5W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 6-WLCSP (1.47x1.47)
- KGF12N05-400-SP Renesas, MOSFET N-CH 5.5V 12A 6WLCSP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
KGF12N05-400-SP, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
