ISL84543IPZ Images
- Manufacturer: Renesas Electronics
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 8-DIP (0.300, 7.62mm)
- Description: IC SWITCH DUAL SPST 8DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ISL84543IPZ Specifications:
- MfrPart.: ISL84543IPZ
- Mfr: Renesas Electronics America Inc
- Description: IC SWITCH DUAL SPST 8DIP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPST - NO/NC
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 2
- On-StateResistance(Max): 60Ohm
- Channel-to-ChannelMatching(ΔRon): 800mOhm
- Voltage-SupplySingle(V+): 2.7V ~ 12V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 100ns, 75ns
- -3dbBandwidth: -
- ChargeInjection: 1pC
- ChannelCapacitance(CS(off)CD(off)): 8pF, 8pF
- Current-Leakage(IS(off))(Max): 100pA
- Crosstalk: -90dB @ 1MHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Through Hole
- Package/Case: 8-DIP (0.300, 7.62mm)
- ISL84543IPZ Renesas, IC SWITCH DUAL SPST 8DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ISL84543IPZ, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
