ISL84522IB Images
- Manufacturer: Renesas Electronics
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-SOIC (0.154, 3.90mm Width)
- Description: IC SWITCH QUAD SPST 16SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ISL84522IB Specifications:
- MfrPart.: ISL84522IB
- Mfr: Renesas Electronics America Inc
- Description: IC SWITCH QUAD SPST 16SOIC
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPST - NO
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 100Ohm
- Channel-to-ChannelMatching(ΔRon): 1Ohm
- Voltage-SupplySingle(V+): 2V ~ 12V
- Voltage-SupplyDual(V±): ±2V ~ 6V
- SwitchTime(TonToff)(Max): 80ns, 30ns
- -3dbBandwidth: -
- ChargeInjection: 1pC
- ChannelCapacitance(CS(off)CD(off)): 2pF, 2pF
- Current-Leakage(IS(off))(Max): 1nA
- Crosstalk: -90dB @ 100kHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.154, 3.90mm Width)
- ISL84522IB Renesas, IC SWITCH QUAD SPST 16SOIC, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ISL84522IB, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
