HI4P0509-5Z96 Images
- Manufacturer: Renesas Electronics
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 20-LCC (J-Lead)
- Description: IC MULTIPLEXER DUAL 4X1 20PLCC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HI4P0509-5Z96 Specifications:
- MfrPart.: HI4P0509-5Z96
- Mfr: Renesas Electronics America Inc
- Description: IC MULTIPLEXER DUAL 4X1 20PLCC
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 400Ohm
- Channel-to-ChannelMatching(ΔRon): 20Ohm
- Voltage-SupplySingle(V+): -
- Voltage-SupplyDual(V±): ±15V
- SwitchTime(TonToff)(Max): 250ns, 250ns (Typ)
- -3dbBandwidth: -
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 10pF, 12pF
- Current-Leakage(IS(off))(Max): 30pA (Typ)
- Crosstalk: -
- OperatingTemperature: 0°C ~ 75°C (TA)
- MountingType: Surface Mount
- Package/Case: 20-LCC (J-Lead)
- HI4P0509-5Z96 Renesas, IC MULTIPLEXER DUAL 4X1 20PLCC, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
HI4P0509-5Z96, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
