HAT2201WP-EL-E Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-WPAK
- Description: 15A, 100V, N-CHANNEL MOSFET
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HAT2201WP-EL-E Specifications:
- MfrPart.: HAT2201WP-EL-E
- Mfr: Renesas Electronics America Inc
- Description: 15A, 100V, N-CHANNEL MOSFET
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 15A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): -
- RdsOn(Max)@IdVgs: 43mOhm @ 7.5A, 10V
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: 21 nC @ 10 V
- Vgs(Max): -
- InputCapacitance(Ciss)(Max)@Vds: 1450 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): -
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-WPAK
- HAT2201WP-EL-E Renesas, 15A, 100V, N-CHANNEL MOSFET, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
HAT2201WP-EL-E, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
