HAT1069C-EL-E Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 6-CMFPAK
- Description: MOSFET P-CH 12V 4A 6CMFPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HAT1069C-EL-E Specifications:
- MfrPart.: HAT1069C-EL-E
- Mfr: Renesas Electronics America Inc
- Description: MOSFET P-CH 12V 4A 6CMFPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 12 V
- Current-ContinuousDrain(Id)@25°C: 4A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 1.8V, 4.5V
- RdsOn(Max)@IdVgs: 52mOhm @ 1.5A, 4.5V
- Vgs(th)(Max)@Id: 1.2V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 16 nC @ 4.5 V
- Vgs(Max): ±8V
- InputCapacitance(Ciss)(Max)@Vds: 1380 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 900mW (Ta)
- OperatingTemperature: 150°C
- MountingType: Surface Mount
- SupplierDevicePackage: 6-CMFPAK
- HAT1069C-EL-E Renesas, MOSFET P-CH 12V 4A 6CMFPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
