DG508ACJZ Images
- Manufacturer: Renesas Electronics
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-DIP (0.300, 7.62mm)
- Description: IC MULTIPLEXER 8X1 16DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG508ACJZ Specifications:
- MfrPart.: DG508ACJZ
- Mfr: Renesas Electronics America Inc
- Description: IC MULTIPLEXER 8X1 16DIP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: -
- Multiplexer/DemultiplexerCircuit: 8:1
- NumberofCircuits: 1
- On-StateResistance(Max): 400Ohm
- Channel-to-ChannelMatching(ΔRon): 24Ohm
- Voltage-SupplySingle(V+): -
- Voltage-SupplyDual(V±): ±15V
- SwitchTime(TonToff)(Max): 1.5µs, 1µs
- -3dbBandwidth: -
- ChargeInjection: 4pC
- ChannelCapacitance(CS(off)CD(off)): 5pF, 25pF
- Current-Leakage(IS(off))(Max): 1nA
- Crosstalk: -
- OperatingTemperature: 0°C ~ 70°C (TA)
- MountingType: Through Hole
- Package/Case: 16-DIP (0.300, 7.62mm)
- DG508ACJZ Renesas, IC MULTIPLEXER 8X1 16DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG508ACJZ, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
