DG409DYZ Images
- Manufacturer: Renesas Electronics
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-SOIC (0.154, 3.90mm Width)
- Description: IC MULTIPLEXER DUAL 4X1 16SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG409DYZ Specifications:
- MfrPart.: DG409DYZ
- Mfr: Renesas Electronics America Inc
- Description: IC MULTIPLEXER DUAL 4X1 16SOIC
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Bulk
- Series: -
- PartStatus: Active
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 100Ohm
- Channel-to-ChannelMatching(ΔRon): 15Ohm (Max)
- Voltage-SupplySingle(V+): 5V ~ 34V
- Voltage-SupplyDual(V±): ±5V ~ 20V
- SwitchTime(TonToff)(Max): 150ns, 150ns
- -3dbBandwidth: -
- ChargeInjection: 20pC
- ChannelCapacitance(CS(off)CD(off)): 3pF, 14pF
- Current-Leakage(IS(off))(Max): 500pA
- Crosstalk: -
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.154, 3.90mm Width)
- DG409DYZ Renesas, IC MULTIPLEXER DUAL 4X1 16SOIC, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG409DYZ, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
