DG401DJ Images
- Manufacturer: Renesas Electronics
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-DIP (0.300, 7.62mm)
- Description: CMOS ANALOG SWITCH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG401DJ Specifications:
- MfrPart.: DG401DJ
- Mfr: Intersil (Now part of Renesas Electronics America Inc)
- Description: CMOS ANALOG SWITCH
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPST - NO
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 2
- On-StateResistance(Max): 45Ohm
- Channel-to-ChannelMatching(ΔRon): -
- Voltage-SupplySingle(V+): -
- Voltage-SupplyDual(V±): ±15V
- SwitchTime(TonToff)(Max): 150ns, 100ns
- -3dbBandwidth: -
- ChargeInjection: 60pC
- ChannelCapacitance(CS(off)CD(off)): 12pF, 12pF
- Current-Leakage(IS(off))(Max): 500pA
- Crosstalk: -94.8dB @ 1MHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Through Hole
- Package/Case: 16-DIP (0.300, 7.62mm)
- DG401DJ Renesas, CMOS ANALOG SWITCH, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG401DJ, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
