DG211CJ Images
- Manufacturer: Renesas Electronics
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-DIP (0.300, 7.62mm)
- Description: IC SWITCH QUAD SPST 16DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG211CJ Specifications:
- MfrPart.: DG211CJ
- Mfr: Renesas Electronics America Inc
- Description: IC SWITCH QUAD SPST 16DIP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPST - NC
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 175Ohm
- Channel-to-ChannelMatching(ΔRon): -
- Voltage-SupplySingle(V+): -
- Voltage-SupplyDual(V±): ±15V
- SwitchTime(TonToff)(Max): 460ns, 450ns
- -3dbBandwidth: -
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 5pF, 5pF
- Current-Leakage(IS(off))(Max): 5nA
- Crosstalk: -90dB @ 100kHz
- OperatingTemperature: 0°C ~ 70°C (TA)
- MountingType: Through Hole
- Package/Case: 16-DIP (0.300, 7.62mm)
- DG211CJ Renesas, IC SWITCH QUAD SPST 16DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG211CJ, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
