DG202AK Images
- Manufacturer: Renesas Electronics
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-CDIP (0.300, 7.62mm)
- Description: QUAD SPST ANALOG SWITCH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG202AK Specifications:
- MfrPart.: DG202AK
- Mfr: Intersil (Now part of Renesas Electronics America Inc)
- Description: QUAD SPST ANALOG SWITCH
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Bulk
- Series: -
- PartStatus: Active
- SwitchCircuit: SPST - NO
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 175Ohm
- Channel-to-ChannelMatching(ΔRon): -
- Voltage-SupplySingle(V+): ±4.5V ~ 18V
- Voltage-SupplyDual(V±): ±4.5V ~ 18V
- SwitchTime(TonToff)(Max): 600ns, 450ns
- -3dbBandwidth: -
- ChargeInjection: 20pC
- ChannelCapacitance(CS(off)CD(off)): 5pF, 5pF
- Current-Leakage(IS(off))(Max): 1nA
- Crosstalk: -90dB @ 100kHz
- OperatingTemperature: -55°C ~ 125°C (TA)
- MountingType: Through Hole
- Package/Case: 16-CDIP (0.300, 7.62mm)
- DG202AK Renesas, QUAD SPST ANALOG SWITCH, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG202AK, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
