2SK3813-AZ Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-251
- Description: MOSFET N-CH 40V 60A TO251
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2SK3813-AZ Specifications:
- MfrPart.: 2SK3813-AZ
- Mfr: Renesas Electronics America Inc
- Description: MOSFET N-CH 40V 60A TO251
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 60A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 5.3mOhm @ 30A, 10V
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: 96 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 5500 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 1W (Ta), 84W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-251
- 2SK3813-AZ Renesas, MOSFET N-CH 40V 60A TO251, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
2SK3813-AZ, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
