2SK3481-AZ Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220AB
- Description: MOSFET N-CH 100V 30A TO220AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2SK3481-AZ Specifications:
- MfrPart.: 2SK3481-AZ
- Mfr: Renesas Electronics America Inc
- Description: MOSFET N-CH 100V 30A TO220AB
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 30A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 50mOhm @ 15A, 10V
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: 48 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2300 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 1.5W (Ta), 56W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220AB
- 2SK3481-AZ Renesas, MOSFET N-CH 100V 30A TO220AB, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
2SK3481-AZ, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
