2SJ690-T1B-AT Images
- Manufacturer: Renesas Electronics
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SC-96-3, Thin Mini Mold
- Description: MOSFET P-CH 30V 2.5A SC96-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2SJ690-T1B-AT Specifications:
- MfrPart.: 2SJ690-T1B-AT
- Mfr: Renesas Electronics America Inc
- Description: MOSFET P-CH 30V 2.5A SC96-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 2.5A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
- RdsOn(Max)@IdVgs: 119mOhm @ 1A, 4.5V
- Vgs(th)(Max)@Id: 1.5V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 5.2 nC @ 4.5 V
- Vgs(Max): ±12V
- InputCapacitance(Ciss)(Max)@Vds: 450 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 200mW (Ta)
- OperatingTemperature: 150°C
- MountingType: Surface Mount
- SupplierDevicePackage: SC-96-3, Thin Mini Mold
- 2SJ690-T1B-AT Renesas, MOSFET P-CH 30V 2.5A SC96-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
2SJ690-T1B-AT, Renesas authentic parts in stock from Renesas authorized distributors, order today, can ship immediately.
